25G SFP28 Transceiver up to 10km

Compliant with SFF-8431, SFF 8472, IEEE 802.3 CC, and RoHS

Code: 25GBASE-BiDi LR - G
Regular price £147.00 GBP
Regular price Sale price £147.00 GBP
Sale Sold out
Tax included.

Item in Stock | Usually dispatched within 24 hours

PRODUCT FEATURES - Supports 24.3Gb/s to 26.5Gb/s bit rates - Up to 10km transmission on SMF - 1270nm DFB laser and PIN receiver for XPBL-2733B1-10D(A) 1330nm DFB laser and PIN receiver for XPBL-3327B1-10D(A) - Metal enclosure, for lower EMI - 2-wire interface with integrated Digital Diagnostic monitoring - Specifications compliant with SFF 8472 - Compliant with SFP+ MSA with LC connector - Single 3.3V power supply - Power dissipation < 1.2 W - Case operating temperature range: Commercial: 0?C to +70?C Industrial: -40?C to +85?C APPLICATIONS - 25G Ethernet - CPRI 10 STANDARDS - Compliant to SFF-8431 - Compliant to SFF 8472 - Compliant to IEEE 802.3 CC - RoHS Compliant

Westbury's 25Gbps SFP28 optical transceiver is capable of supporting transmission distances up to 10km of SMF. The unique advantage is the Bi-Directional LC connector which utilises a single LC connector for the optical transmit and receive functions. You will need to specify which of the 4 CWDM bands you would like to operate across, or contact one of our team to discuss which is most suitable. There are two versions, the commercial temp range (0C to +70C) and industrial version (-40C to +85C). The typical applications being 25G Ethernet and is also suitable for CPRI-10 for mobile fronthaul applications where distance and latency is critical. The two types are compliant with SFF-8431, SFF-8472, IEEE 802.3 CC, and is RoHS compliant.
