40G QSFP+ LR4 Transceiver

Compliant to IEEE 802.3ba, SFF-8436, and RoHS

Code: 40GBASE-T-LR4 - G
Regular price £204.00 GBP
Regular price Sale price £204.00 GBP
Sale Sold out
Tax included.

Item in Stock | Usually dispatched within 24 hours

PRODUCT FEATURES - 4 CWDM lanes Mux/Demux design - Up to 11.1Gbps Data rate per wavelength - Up to 10km transmission on SMF - Electrically hot-pluggable - Digital Diagnostics Monitoring Interface - Compliant with QSFP+ MSA with LC connector - Case operating temperature range:0?C to 70?C - Power dissipation < 2.5 W APPLICATIONS - 40G Ethernet - Data Center and LAN STANDARDS - Compliant to IEEE 802.3ba - Compliant to SFF-8436 - RoHS Compliant

Westbury's QSFP+ LR4 module is designed to operate over single-mode fibre using 4X10 CWDM channel in 1310nm band for links up to 10km. The module converts 4 inputs channel of 10Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data. The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311 and 1331 nm. It contains a duplex LC connector for the optical interface and a 38-pin connector for the electrical interface. Single-mode fibre (SMF) is applied in this module. This product converts the 4-channel 10Gb/s electrical input data into CWDM optical signals (light), by a 4-wavelength Distributed Feedback Laser (DFB) array. The 4 wavelengths are multiplexed into a single 40Gb/s data, propagating out of the transmitter module via the SMF. The receiver module accepts the 40Gb/s optical signals input, and de-multiplexes it into 4 CWDM 10Gb/s channels. Each wavelength light is collected by a discrete photo diode, and then outputted as electric data after amplified by a TIA. The product is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP+ Multi-Source Agreement (MSA) and compliant to 40G QSFP+ LR4 of IEEE 802.3ba.
